High-Performance Wireless 2D Scanning for Retail, Logistics & Manufacturing

The Unitech MS852B Plus is a professional Bluetooth 2D barcode scanner designed for mobility, industrial durability, and advanced barcode compatibility.

It supports 1D and 2D barcodes, including OCR, DotCode, and Digimarc formats, making it suitable for retail, warehousing, manufacturing, and logistics operations in the UAE.

This product is supplied within the UAE.

Product Overview

The MS852B Plus features a 1280 × 800 global shutter megapixel sensor for accurate barcode capture, including mobile screen barcodes and damaged or low-quality prints.

It supports Bluetooth dual-mode technology (Bluetooth LE® V4.2 and Bluetooth® 2.1+EDR Class 1) with wireless coverage up to 100 meters (line of sight).

The scanner includes batch mode and auto mode buffer memory, ensuring data is stored when out of range and automatically transmitted when reconnected.

With IP42 protection and 2.1-meter drop resistance, it is designed for demanding business environments.

Key Features

• 2D imager (reads 1D & 2D barcodes)
• Megapixel 1280 × 800 global shutter sensor
• OCR support (passport / ID scanning capability)
• Supports DotCode and Digimarc
• Bluetooth dual mode (LE 4.2 & 2.1+EDR Class 1)
• Wireless range up to 100m (line of sight)
• 2850mAh rechargeable battery
• Up to 25 hours operation
• Up to 60,000 scans (1 scan/sec test condition)
• 7.5MB memory (approx. 590,000 barcodes)
• IP42 rating
• 2.1m drop resistance
• 10 million trigger life cycle
• LED, beeper & vibration indicators

Technical Specifications

Optical & Performance

• Sensor: 1280 × 800 Global Shutter
• Optical Resolution: 1D 3mil / 0.075mm
• Ambient Light: 100,000 Lux
• Skew: ±60°
• Pitch: ±60°
• Roll: 0–360°
• Minimum Print Contrast: 20%

Typical DOF Examples (PCS 80%):

• 13 mil UPC: 3.4cm – 57.3cm
• 20 mil Code 39: 3.5cm – 80cm
• 15 mil QR Code: 3.3cm – 39cm

Wireless & Communication

• Bluetooth LE® V4.2
• Bluetooth® 2.1+EDR (Class 1)
• Wireless Coverage: Up to 100m (line of sight)
• Profiles: HID & Serial Port
• Interfaces: USB, RS232
• Memory Buffer: 7MB (batch) / 20KB (auto mode)

Electrical

• Battery: 2850mAh rechargeable, replaceable
• Charging Time: <6.5 hours
• Operating Time: >25 hours
• Indicators: LED, beeper, vibration

Environmental

• Drop Resistance: 2.1m (scanner only)
• IP Rating: IP42
• Operating Temperature: -10°C to 50°C
• Storage Temperature: -40°C to 70°C
• Humidity: 95% non-condensing
• ESD: 8K contact / 15K air

Supported Barcode Types

1D

Code 39, Code 128, UPC, EAN, GS1 DataBar, MSI, Codabar, Interleaved 2 of 5, Matrix 2 of 5, and other standard 1D formats.

2D

QR Code, Data Matrix, PDF417, MicroPDF417, Aztec, MaxiCode, Han Xin, DotCode, Grid Matrix.

Special

OCR, Digimarc barcode support.

What Comes in the Box

• MS852B Plus Scanner with battery
• Cradle
• Interface Cable

Business Applications

• Retail POS systems
• Warehouse inventory management
• Logistics barcode processing
• Manufacturing production tracking
• ID / OCR document scanning
• Mobile coupon and screen barcode scanning

If you require a basic wired scanner, see our barcode scanner collection.

Why Buy from REPRONIX®

• UAE-based business supply
• Genuine products sourced from authorized distribution channels
• Clear VAT invoicing
• 36-month manufacturer warranty support
• Pre-sale compatibility consultation available
• Transparent policies with no misleading claims

We focus on long-term business reliability rather than short-term sales promises.

UAE Supply & VAT

• Supplied within UAE
• VAT applicable as per UAE law
• Delivery timelines follow our Shipping Policy
• Returns handled under our Return & Refund Policy
• Warranty terms available in our Warranty Policy

FAQ - Unitech MS852B Plus

Q: Does the MS852B Plus support mobile phone screen scanning?
A: Yes. It supports scanning 1D and 2D barcodes displayed on mobile screens.

Q: What is the maximum wireless range?
A: Up to 100 meters in open line-of-sight conditions. Obstacles may reduce effective range.

Q: Does it support OCR and special barcode formats?
A: Yes. It supports OCR, DotCode, and Digimarc barcode formats.

Warranty

36-month hardware warranty covering manufacturing defects under normal use.

Accessories carry warranty as per manufacturer policy.

Physical damage beyond stated drop specification is not covered.

Disclaimer

Specifications are based on manufacturer documentation. Performance may vary depending on barcode condition, environmental factors, and configuration.

Bluetooth range depends on surrounding physical conditions.

Compatibility with software systems should be verified before purchase.
