Hands-Free USB QR & Barcode Scanner for POS and Retail

The REPRONIX® RX-6700 is a desktop barcode scanning platform designed for hands-free operation in supermarkets, retail counters, bookstores, and payment environments.

With automatic induction scanning, the RX-6700 activates when a barcode enters its field of view and returns to sleep mode when idle, helping reduce energy consumption and extend device lifespan.

It supports both printed and screen-based barcodes, making it suitable for payment QR codes, product labels, and digital coupons.

Overview

• Desktop hands-free scanning platform
• 1D & 2D barcode support
• QR code and mobile screen code compatible
• USB plug & play
• Automatic induction continuous scanning
• Suitable for POS, retail, and commercial environments

Key Features

• CMOS global exposure image sensor
• 640 × 480 optical resolution
• Automatic activation & sleep mode
• Red LED illumination (617nm)
• Buzzer and LED status indicators
• USB-HID keyboard mode supported
• USB virtual COM and RS232 options available
• Durable ABS + PC housing

Scanning Performance

• Scan Type: CMOS global exposure
• Resolution: 640 × 480
• Scanning Rate: Up to 120 scans/second
• Field of View: 48° (H) × 30° (V)
• Scan Angle: ±60°, ±54°, 360° rotation support
• Minimum Resolution: 4 mil
• Print Contrast Requirement: ≥ 20%

Actual performance may vary depending on barcode size, lighting conditions, and print quality.

Decoding Capability

1D Barcodes

EAN-13, EAN-8, UPC-A, UPC-E, Code 128, Code 39, Code 93, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 11, Codabar, MSI, RSS-14, RSS Limited, RSS Expanded, GS1 Composite and other common formats.

2D Barcodes

QR Code, Data Matrix, PDF417, Micro PDF417, Micro QR, MaxiCode, Aztec Code, Han Xin Code, Code16K.

Supports reading from mobile phone screens and digital displays.

Connectivity & Interface

• Interface Type: USB Type-B
• Communication Modes:
• USB HID (Keyboard mode)
• USB Virtual COM
• RS232 Serial

No additional drivers required for standard USB HID mode in most POS systems.

Electrical Specifications

• Input Voltage: DC 5V ±10%
• Working Current: 240 mA
• Standby Current: 190 mA

Powered directly via USB.

Physical Specifications

• Product Size: 158 × 92 × 94 mm
• Weight (Net): Approx. 335 g
• Gross Weight (Single Unit): Approx. 0.5 kg
• Cable: 1.3m straight cable
• Material: ABS + PC
• Color: Black

Environmental Conditions

• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to +70°C
• Humidity: 5%–95% non-condensing

Applications

• Supermarket cashier counters
• Retail stores
• Bookstores
• Shopping malls
• QR payment scanning
• POS terminals
• Commercial environments

Packaging

• 1 × REPRONIX RX-6700 Scanner
• USB Cable
• User Guide
• Retail box

Single package size: 21 × 17 × 15 cm

Warranty & Support

• Warranty: 1 Year
• After-sales support:
• Online technical support
• Call center assistance

UAE support available under REPRONIX®.

FAQ - REPRONIX® RX-6700

Q: Does the REPRONIX® RX-6700 support QR codes from mobile phone screens?

A: Yes. The RX-6700 supports scanning both printed barcodes and digital screen codes, including QR payment codes displayed on smartphones, tablets, and POS terminals. Performance may vary depending on screen brightness and resolution.

Q: Is the RX-6700 plug-and-play with POS systems?

A: Yes. In USB HID keyboard mode, the scanner works as plug-and-play with most Windows-based POS systems without requiring additional drivers. For advanced integration, USB virtual COM and RS232 modes are also supported.

Q: What types of barcodes can the RX-6700 read?

A: The RX-6700 supports major 1D barcodes such as EAN, UPC, Code 39, Code 128, and GS1 DataBar, as well as 2D barcodes including QR Code, Data Matrix, PDF417, Aztec, and Micro QR. It is suitable for retail, payment, and inventory applications.

OEM Statement

The REPRONIX® RX-6700 is an OEM-configured desktop barcode scanner produced under private mold manufacturing. Technical specifications are based on supplier documentation and may vary depending on firmware or production batch.

Last Updated: 15 February 2026
