Freedom to Scan Faster — Wireless Performance for Modern Retail

Product Overview

The DS-7500 Wireless Barcode Scanner is a hands-free and handheld 1D/2D scanning solution designed for supermarkets, retail POS counters, warehouses, pharmacies, and logistics operations.

Supporting Bluetooth and 2.4G wireless transmission, the DS-7500 offers flexible deployment with reliable long-range connectivity. Its CMOS global shutter sensor enables fast and accurate scanning of printed barcodes and mobile screen QR codes, improving productivity in high-volume environments.

With a lightweight ergonomic design and long-lasting battery, the DS-7500 is suitable for both fixed POS use and mobile scanning tasks.

Key Features & Highlights

• ✅ Wireless Connectivity – Bluetooth & 2.4G wireless + USB
• ✅ Supports 1D & 2D Barcodes – Including QR, PDF417, Data Matrix
• ✅ Hands-Free & Handheld Modes – Flexible working styles
• ✅ High Scanning Accuracy – 1D ≥4mil, 2D ≥5mil
• ✅ Fast Scan Performance – Up to 200 scans per second
• ✅ CMOS Global Shutter Sensor – Reliable image-based decoding
• ✅ Wide Scanning Angles – 360° rotation, ±55° pitch & yaw
• ✅ Mobile Screen Scanning – Reads QR codes from phones
• ✅ Visual & Audio Feedback – LED indicator and buzzer
• ✅ Long Wireless Range – Up to 100m (2.4G outdoor)
• ✅ Durable Design – Drop resistance up to 2 meters

Barcode Decoding Capability

1D Barcodes Supported:
EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, UCC/EAN-128, Codabar, ITF-6, ITF-14, ISBN, ISSN, MSI-Plessey, GS1 Databar, GS1 Composite, Code 11, Industrial 25, Standard 25, Matrix 2 of 5

2D Barcodes Supported:
QR Code, Data Matrix, PDF417, Aztec, Maxicode, Micro QR

Technical Specifications (Summary)

Model: DS-7500
Scanner Type: Wireless Barcode Scanner
Scan Element Type: CMOS (Global Shutter)
Resolution: 640 × 480
Colour Depth: 32-bit

Scan Speed:
Up to 200 scans per second

Scan Accuracy:
1D ≥ 4mil
2D ≥ 5mil

Interfaces:
USB / Bluetooth / 2.4G Wireless

Transmission Distance:
Bluetooth: up to 30 m (outdoor)
2.4G Wireless: up to 100 m (outdoor)

Battery Capacity:
2000 mAh rechargeable battery

Charging Time:
Approx. 4–5 hours

Weight:
Approx. 300 g

Scanning Performance

Scan Depth of Field (Typical):

• EAN-13 (13mil): 50 – 220 mm
• Code39 (5mil): 40 – 100 mm
• QR Code (20mil): 25 – 240 mm
• Data Matrix (10mil): 50 – 100 mm
• PDF417 (6.67mil): 30 – 140 mm

Print Contrast: ≥20%

System Compatibility

• Windows XP / 7 / 8 / 10
• macOS
• Android
• Linux

Driver Requirement: Plug-and-play (no driver installation needed)

Typical Applications

• 🛒 Supermarkets & retail POS systems
• 📦 Warehousing & inventory management
• 🏥 Pharmacies & healthcare stores
• 🚚 Logistics & distribution centers
• 🏪 Convenience & specialty stores

Frequently Asked Questions (FAQ)

Q: Does the DS-7500 support wireless and wired operation?

A: Yes. The DS-7500 supports Bluetooth, 2.4G wireless, and USB wired connection for flexible deployment.

Q: Can it scan QR codes from mobile phone screens?

A: Yes. The CMOS image sensor supports reliable scanning of QR codes and 2D barcodes from mobile screens.

Q: Is this scanner suitable for supermarket checkout counters?

A: Yes. The DS-7500 is designed for retail and supermarket POS environments with fast hands-free or handheld scanning.

What’s in the Box

• DS-7500 wireless barcode scanner
• USB charging / data cable
• User documentation

Disclaimer

Product specifications may change without prior notice.
All third-party trademarks are the property of their respective owners and are used for identification purposes only.
